Specification
Fabric Specification
| Colour | Black | |
|---|---|---|
| Fibre Orientation | 0, 95 | |
| Format | Woven Fabric | |
| Filament Count | 3k | |
| Fibre Type | Carbon Fibre | |
| Fibre Specifics | Pyrofil TR30S 3k | |
| Ends | 7 | cm |
| Picks | 7 | cm |
| Weave | 4 x 4 Twill |
Weight and Dimensions
| Width | 1250 | mm |
|---|---|---|
| Thickness | 0.3 | mm |
| Consolidated Thickness | 0.3 | mm |
| Areal Weight | 285 | g/m² |
Fibre Properties
| UV Resistance | Fully UV Stable | |
|---|---|---|
| Filament Diameter | 7 | µm |
| Tensile Strength | 4120 | MPa |
| Tensile Modulus | 234 | GPa |
| Elongation at Break | 1.8 | % |
| Density | 1.79 | g/cm³ |
General Properties
| Gross Weight | 0.36 | kg |
|---|
Compare
Trade discounts
Bulk Oder Email sales.funique@gmail.com and contact No. +91 9560786511
TABLE 1 | TABLE 2 | TABLE 3 |
|---|---|---|
0-4 | 10-49 | |
Rs=46.20 | Rs=44.40 | Rs=43.20 |
We won’t be beaten on price!
If you believe you’re buying an equivalent product cheaper elsewhere, contact us to discuss your requirements.
Downloads
Shipping Information
Restrictions
This product is not classed as dangerous goods for transport and can be shipped to all destinations without restriction.
Package Size
When packaged, this product is over 1m in length. A small additional handling charge will apply when shipping to some countries and regions. When applicable, this handling charge will be included in the automatic shipping calculation shown on the basket page.
Delivery Cost
To find the delivery cost of this item to your address, add it to your basket and then use the instant shipping calculator on the basket page.
How to Buy
Our 285g carbon fibre cloth is available to buy in 1.25m (49″) width. The fabric is sold by the linear metre. The unit price shown is for 1 linear metre but volume discounts automatically apply for larger quantities of fabric.
Please select your chosen fabric width and then purchase the number of linear metres you require. When purchasing multiple metres the fabric will be supplied in one continuous length on a roll.
